SFF Embedded Computer
DB-cSFF
- Conduction Cooled
- Compact Type 6 COMexpress
- Support up to Intel 13th Gen Core-i7/i5/i3 processor
- 2 x miniPCIe IO expansion slots
- Storage up to 8TB
- I/O – 4 x USB 2.0/3.0, 2 x GbE, 2 x RS232/422, 8 x GPIO, 2 x SATA III, 1 x VGA, 1 x LVDS
- OS Support – Windows, Linux, QNX, VxWorks
- Conformal Coating on Electronics
- Operating Temperature 0°C to 70°C, -20°C to 70°C, -40°C to 85°C
- IO are terminated on MIL-Series 38999 circular connectors
- Design to Meet as per MIL-STD-810x, 461x or JSS 55555
DB-SFF-HPC
- Conduction Cooled
- Basic Type 6 COMexpress
- Support up to Intel 13th Gen Core-Xeon/i7/i5/i3 processor
- IO Expansion slots 1 x XMC site, 2 x miniPCIe
- 1 x MXM slot for GpGPU
- Storage up to 8TB with & without RAID Options
- I/O – 8 x USB 2.0/3.0, up to 4 x GbE, 4 x RS232/422, 8 x GPIO, 4 x SATA III, 2 x DisplayPort, 1 x HDMi, 1 xVGA, 1 x LVDS
- AC or DC Power Supply Input Options
- Conformal Coating on Electronics
- OS Support – Windows, Linux, QNX, VxWorks
- Operating Temperature 0°C to 70°C, -20°C to 70°C, -40°C to 85°C
- IO are terminated on MIL-Series 38999 circular connectors
- Design to Meet as per MIL-STD-810x, 461x or JSS 55555
DB-SFF-VHPC
- Conduction Cooled
- Basic Type 7 COMexpress
- Support up to 10 Core Intel Xeon processor
- IO Expansion slots 2 x XMC site, 2 x miniPCIe, 1 x M.2
- I/O – 8 x USB 2.0/3.0, 2 x GbE, 2 x 10GbE, 2 x RS232/422, 8 x GPIO, 2 x SATA III, 1 x VGA, 1 x DisplayPort/HDMI/DVI
- Storage up to 8TB with & without RAID Options
- Conformal Coating on Electronics
- OS Support – Windows, Linux, QNX, VxWorks
- AC or DC Power Supply Input Options
- Operating Temperature 0°C to 70°C, -20°C to 70°C, -40°C to 85°C
- IO are terminated on MIL-Series 38999 circular connectors
- Design to Meet as per MIL-STD-810x, 461x or JSS 55555
